Description

Data

Operating weight

376 kg

Baseplate W x L

440 x 900 mm

Operating height (without guide handle)

764 mm

Working width (with extension plates)

600 mm

Baseplate thickness

12 mm

Max. Centrifugal force

40 kN

Vibration Frequency

69 Hz

Max. advance travel (depending on soil and environmental factors)

24 m/min

Max. surface capacity (depending on soil and environmental factors)

681 m2/h

Engine Manufacturer & Type

Yanmar L70N air-cooled single cylinder 4-cycle diesel engine

Displacement

320 cm3

Max. Engine Performance (DIN ISO 3046)

4.5 kW @ 3000 rpm

Max. Operating Performance (DIN ISO 3046)

4.3 kW @ 3000 rpm

Fuel consumption

1.4 litres/h

Tank capacity

3.3 litres

Power Train

From drive engine via centrifugal clutch and V-belt directly to the exciter

Fuel Type
