Description

Data

Operating Weight

160 kg

Shipping Weight Incl. Packaging

172 kg

Shipping Size L x W x H

760 x 470 x 1290 mm

Baseplate (W x L)

400 x 703 mm

Working Width

400 mm

Machine Height (without guide handle)

736 mm

Working Height of Handle

800 - 1143 mm

Baseplate Thickness

10 mm

Max. Centrifugal Force

25 kN / 5625 lbf

Vibration Frequency

90 Hz / 90 vpm

Max. Forward / Reverse Travel

21 m/min

Max. Gradeability (depending on soil)

30%

Compacted Area (depending on soil)

504 m2/h

Engine

Hatz 1B20 Air-Cooled Single Cylinder 4-Stroke Diesel Engine

Max. Rated Power @ Rated Speed*

3.5 kW / 4.6 hp @ 3600 rpm

Power Rating Specification

DIN ISO3046

Rated Power Output

1.5 kW / 2.01 hp @ 2800 rpm

Displacement

243 cm3

Fuel Consumption

0.4 litres/h

Tank Capacity

3 litres

Max. allowable tilt of engine in continuous operation

25°

Power Train
