Description |
Metric |
|
||
|
Operating weight |
440 |
kg |
|
|
|
Drum diameter |
560 |
mm |
|
|
|
Drum width |
720 |
mm |
|
|
|
Length x width x height (standard) |
2,135 x 840 x 1,270 |
mm |
|
|
|
Curb clearance |
410 |
mm |
|
|
|
Shipping weight (including packaging) |
465 |
kg |
|
|
|
Shipping size |
1,145 x 965 x 2,160 |
mm |
|
|
|
Water tank capacity |
30 |
l |
|
|
|
Engine Type |
|
|||
|
Engine Type |
|
|||
|
Starting system |
Recoil |
|
|
|
|
Displacement |
337 |
cm3 |
|
|
|
Max. Rated Power at Rated Speed* |
7.1 kW at 3600 rpm |
|
|
|
|
Power Rating Specification |
|
|||
|
Operating speed |
2,400 |
1/min |
|
|
|
Fuel consumption |
3.5 |
l/h |
|
|
|
Fuel tank capacity |
7 |
l |
|
|
|
Total centrifugal force |
15.2 |
kN |
|
|
|
Frequency |
70 |
Hz |
|
|
|
Dynamic linear force per drum (f/r) |
21 |
N/mm |
|
|
|
Transmission |
Hydrostatic |
|
|
|
|
Variable speeds - Forward |
0 - 61 |
m/min |
|
|
|
Variable speeds - Reverse |
0 - 2.7 |
km/h |
|
|
|
Variable speeds - Reverse |
0 - 46 |
m/min |
|
|
|
Compacted area |
up to 2,630 |
m2/h |
|
|
|
Max. gradeability (depending on soil) |
15 |
% |
|
|
|
Variable speeds - Forward |
0 - 3.7 |
km/h |
|
|
